Modular and configurable LED light line system
| Product highlights PROLAMP series | |||
| Designation | Article | Description | Special features |
| PROLAMP30Hcri90hm surface mounted | 200616 | 45 W | silver | 1500 mm | opal+ Push/DALI dimmable | CCT | » Human Centric Lighting » White dynamic lighting |
| L-Form PROLAMP30HIDhs pendant | 200617 | 120 W | white | 1200 mm | prismatic 4.000 K | SkyBlue | 2-part | » Prismatic cover » Indirect lighting with SkyBlue |
| PROLAMP40Dhm rectangle surface mounted | 200618 | 124W | weiß | 2000 x 2000 mm | opal+ TRIAC dimmable | 3.000 K | 6-part | » Triac dimmable » Can be connected horizontally with corner connectors |
| PROLAMP30FIDhm pendant | 200619 | 248 W | silver | 5884 mm | double asymmetrical 25° Push/DALI dimmable | 4.000 K | 4.000 K | 2-part | » Special lens cover » Indirect lighting |
| PROLAMP40IDhs pendant | 200620 | 75 W | weiß | 1500 mm | opal+ Zigbee + Sys-Pro dimmable | CCT | 2.700 K | » Smart home-compatible lighting solution
» Dynamic white lighting |
| PROLAMP30FIDhs pendant | 200621 | 78 W | weiß | 2356 mm | Lens 60° Sys-Pro Funk dimmable | CCT | RGB+WW | » Indirect RGB+WW lighting
» Dynamic white lighting |
| PROLAMP30HIDcri90hs pendant | 200622 | 68 W | black | 1500 mm | U-Cover Push/DALI dimmable | CCT | CCT | » U-Cover » Dynamic white lighting |
| PROLAMP30Hcri90hm pendant | 200623 | 19 W | white | 600 mm | U-Cover | 3.000 K | » U-Cover |
| PROLAMP30Hcri90hs surface mounted | 200624 | 89 W | white | 3000 mm | opal+ | 3.000 K | » Comprehensive illumination |
| PROLAMP30Fhs pendant | 200625 | 50 W | white | 2356 mm | asymmetrical 25° 4.000 K | » Special lens cover |
Modular and configurable LED strip lighting system
Modular_lighting_system_graphic The versatile light line systems from ISOLED emphasize your architectural concept with the individually confi gurable elements and thus offer complete freedom of design.
With the LED modular light stripes you benefi t from:
-
flexible lighting design +
customerspecific modification -
individual installation and
suspension options -
a wide selection of dimming
variants, light and profi le colors,
and covers
The modular LED light strips from ISOLED®. are individually configured and can be perfectly integrated into your architectural concept. You have the choice of different types of installation, light and profi le colors as well as covers and thus absolute freedom of design for the lighting in your rooms. Perfect for offi ces and workplaces, conference rooms, hallways and much more!
Set specific accents!
For your specific project, we offer an individual colour selection for the linear luminaire profile on request. This gives your premises a unique touch that is precisely matched to your architectural requirements.
OFFICE
MUSEUMS
SEMINAR AND
EVENT ROOMS
LIVING AREAS
HOTEL INDUSTRY
SCHOOLS AND UNIVERSITIES
Modular and Configurable LED Linear Lighting System from ISOLED
Versatile linear lighting systems for your architectural vision
ISOLED presents modular LED linear lighting systems that are not only flexible in design but also offer complete freedom in configuration. Our lighting systems highlight your architectural concept and allow for individually configurable elements.
Features of ISOLED’s Modular LED Linear Lights:
- Flexibility in lighting design: Adjust the light precisely to the requirements of your space.
- Custom modifications: Design your linear lighting system according to your individual needs.
- Individual mounting and suspension options: Adapt the installation to the structure of your room.
- Wide selection of dimming options, light and profile colors, and covers: Design the lighting entirely to your taste.
Our modular LED linear lights integrate perfectly into your architectural concept and offer:
- Various mounting types: Adapt the linear lights to different spaces.
- Different light and profile colors: Create a unique atmosphere in offices, conference rooms, and corridors.
- Various covers: Emphasize the architectural features of your building.
ISOLED’s linear lighting systems are suitable for office spaces, workplaces, conference rooms, and more. Discover the future of lighting!
Benefits of ISOLED’s Linear Lighting Systems:
- High flexibility: Configure the lighting system according to your requirements and create the perfect luminaire for your project.
- Professional consultation: We provide advice throughout the entire project. Schedule a consultation for a non-binding initial discussion.
- Quality & satisfaction: Our product meets all quality standards, thanks to batch-controlled quality assurance.
- Fast production time: In just five days, we produce up to ten luminaires in Austria*. Set accents precisely!
*Subject to availability
For your specific project, we offer individual color options for the linear luminaire profile upon request. This gives your spaces a unique touch, precisely tailored to your architectural requirements. Unleash your creativity and create the perfect lighting solution with ISOLED.
